| Aliases | |
| Date | |
| CPUs | 2 |
| Clock speed | 300 MHz |
| Processor | Superscalar SPARC Version 9 UltraSPARC II |
| Co-processor | |
| MMU | 64 instruction TLB entries, 64 data TLB entries, 8192 hardware contexts. |
| Motherboard | |
| On-chip cache | 32 KB: 16 KB data, 16 KB instruction |
| External cache | 2 MB / CPU |
| Memory |
(16) SIMM memory
512 MB maximum (with 32MB SIMMs, in pairs) 1 GB maximum (with 64MB SIMMs, in pairs) 2 GB maximum (with 128MB SIMMs, in pairs) (Note: Install SIMMs in sets of four for best system performance) |
| Speed | |
| Chassis type | |
| Bus |
(3) full-size v 2.1 PCI slots,
32 / 64 bit, 33 MHz.
(1) full-size v 2.1 PCI slots, 32 / 64 bit, 33 / 66 MHz. |
| Ports |
(2) Serial, RS-232C/RS-423 ports (DB25)
(1) Parallel, Centronics-compatible parallel port (DB25)(ECP mode capable) 40 MB/sec UltraSCSI (SCSI-3)(synchronous), (1) Ethernet/Fast Ethernet, STP (10baseT and 100baseT) or MII connector Alarms card DB15 connector; three dry contact outputs (minor, major, critical), external reset input |
| Internal storage | Two disk bays |
| Graphics | |
| Power supply |
Netra T1125 uses (AC) - 100-240VAC 47-63Hz
Netra T1120 uses (DC) - -48/60VDC nominal, 350W, dual input |
| Architecture | sun4u |
| OS's supported | |
| Notes | |
| Comments | |
| See also.. |
